| Sr. No. |
Name |
Description |
| |
Platform Height — Elevated |
43 ft (13.11 m) |
| A. |
Platform Height — Lowered |
5 ft 10.4 in. (1.79 m) |
| B. |
Platform Railing Height |
3 ft 7.5 in. (1.1 m) |
| C. |
Overall Height — Rails Lowered |
7 ft 2.4 in. (2.19 m) |
| D. |
Platform Size |
86 x 150 in. (2.18 x 3.81 m) |
| E. |
Platform Extension |
4 ft (1.22 m) |
| F. |
Overall Length |
12 ft 8 in. (3.86 m) |
| G. |
Overall Width |
7 ft 10 in. (2.39 m) |
| H. |
Wheelbase |
9 ft 8 in. (2.95 m) |
| I. |
Ground Clearance |
12 in. (30 cm) |
| |
Platform Capacity |
1,500 lb (680 kg) |
| |
Capacity on Platform Extension |
500 lb (227 kg) |
| |
Capacity with Dual Extensions |
1,250 lb (567 kg) |
| |
Maximum Drive Height |
Full Height |
| |
Weight w/One Extension* |
15,300 lb (6,940 kg) |
| |
Ground Bearing Pressure** |
169 psi (11.83 kg/cm2) |
